ZyWALL 2 and ZyWALL 2WE
10-6 Remote Node Setup
Table 10-2 Fields in Menu 11.1 (PPPoE Encapsulation Specific)
FIELD DESCRIPTION EXAMPLE
Session
Options
Idle Timeout
Type the length of idle time (when there is no traffic from the ZyWALL to
the remote node) in seconds that can elapse before the ZyWALL
automatically disconnects the PPPoE connection. This option only
applies when the ZyWALL initiates the call. 100
seconds
(default)
10.3.3 PPTP Encapsulation
If you change the Encapsulation to PPTP in menu 11.1, then you will see the next screen. Please see the
appendices for information on PPTP.
Figure 10-4 Menu 11.1: Remote Node Profile for PPTP Encapsulation
The next table shows how to configure fields in menu 11.1 not previously discussed above.
Table 10-3 Fields in Menu 11.1 (PPTP Encapsulation)
FIELD DESCRIPTION EXAMPLE
Encapsulation Press [SPACE BAR] and then [ENTER] to select PPTP. You must
also go to menu 11.3 to check the IP Address setting once you
have selected the encapsulation method. PPTP
Menu 11.1 - Remote Node Profile
Rem Node Name= ChangeMe Route= IP
Active= Yes
Encapsulation= PPTP Edit IP= No
Service Type= Standard Telco Option:
Service Name=N/A Allocated Budget(min)= 0
Outgoing= Period(hr)= 0
My Login= Schedules=
My Password= ******** Nailed-up Connections=
Authen= CHAP/PAP
Session Options:
PPTP : Edit Filter Sets= No
My IP Addr= Idle Timeout(sec)= 100
My IP Mask=
Server IP Addr=
Connection ID/Name= Edit Traffic Redirect= No
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
