ZyWALL 2 and ZyWALL 2WE
68 Boot Commands
Appendix P
Boot Commands
The BootModule AT commands execute from within the router’s bootup software, when debug mode is
selected before the main router firmware (ZyNOS) is started. When you start up your ZyWALL, you are
given a choice to go into debug mode by pressing a key at the prompt shown in the following screen. In
debug mode you have access to a series of boot module commands, for example
ATUR (for uploading
firmware) and ATLC (for uploading the configuration file). These are already discussed in the Firmware
and Configuration File Maintenance chapter.
Diagram P-1 Option to Enter Debug Mode
Enter ATHE to view all available ZyWALL boot module commands as shown in the next screen. ATBAx
allows you to change the console port speed. The x denotes the number preceding the colon to give the
console port speed following the colon in the list of numbers that follows; for example
ATBA3 will give a
console port speed of 9.6 Kbps. ATSE displays the seed that is used to generate a password to turn on the
debug flag in the firmware. The ATSH command shows product related information such as boot module
version, vendor name, product model, RAS code revision, etc. ATGO allows you to continue booting the
system. Most other commands aid in advanced troubleshooting and should only be used by qualified
engineers.
Bootbase Version: V1.02 | 08/08/2001 15:40:50
RAM: Size = 16384 Kbytes
DRAM Post: Testing: 16384K OK
FLASH: Intel 16M
ZyNOS Version: V3.50(WB.0)b3 | 08/08/2001 16:21:27
Press any key to enter debug mode within 3 seconds.
