ZyWALL 2 and ZyWALL 2WE
10-8
Remote Node Setup
Table 10-4 Remote Node Network Layer Options Menu Fields
FIELD
DESCRIPTION
EXAMPLE
IP Address
Assignment
If your ISP did not assign you an explicit IP address, press [SPACE
BAR] and then [ENTER] to select Dynamic; otherwise select Static
and enter the IP address & subnet mask in the following fields.
Dynamic
(default)
(Rem) IP
Address
If you have a Static IP Assignment, enter the IP address assigned to
you by your ISP.
(Rem) IP
Subnet Mask
If you have a Static IP Assignment, enter the subnet mask assigned to
you.
Gateway IP
Addr
This field is applicable to Ethernet encapsulation only. Enter the
gateway IP address assigned to you if you are using a static IP
address.
My WAN
Addr
This field is applicable to PPPoE and PPTP encapsulations only. Some
implementations, especially the UNIX derivatives, require the WAN link
to have a separate IP network number from the LAN and each end
must have a unique address within the WAN network number. If this is
the case, enter the IP address assigned to the WAN port of your
ZyWALL.
Note that this is the address assigned to your local ZyWALL, not the
remote router.
Network
Address
Translation
Press [SPACE BAR] and then [ENTER] to select either Full Feature,
None or SUA Only. See the NAT chapter for a full discussion on this
feature.
SUA Only
(default)
Metric
Enter a number from 1 to 15 to set this route’s priority among the
ZyWALL’s routes. The smaller the number, the higher priority the route
has.
1
Private
This field is valid only for PPTP/PPPoE encapsulation. This parameter
determines if the ZyWALL will include the route to this remote node in
its RIP broadcasts. If set to Yes, this route is kept private and not
included in RIP broadcast. If No, the route to this remote node will be
propagated to other hosts through RIP broadcasts.
No
RIP Direction
Press [SPACE BAR] and then [ENTER] to select the RIP direction from
Both/ None/In Only/Out Only. See the LAN Setup chapter for more
information on RIP. The default for RIP on the WAN side is None. It is
recommended that you do not change this setting.
None
(default)
Version Press [SPACE BAR] and then [ENTER] to select the RIP version from
RIP-1/RIP-2B/RIP-2M or None.
N/A
