4.6
USB Interrupt Source Set Register (INTSETR)
Registers
www.ti.com
The USB Interrupt Source Set Register (INTSETR) is shown in
and described in
.
Figure 21. USB Interrupt Source Set Register (INTSETR)
31
25
24
16
Reserved
USB
R-0
W-0
15
13
12
8
7
5
4
0
Reserved
RX
Reserved
TX
R-0
W-0
R-0
W-0
LEGEND: R = Read only; W = Write only; -n = value after reset
Table 22. USB Interrupt Source Set Register (INTSETR) Field Descriptions
Bit
Field
Value
Description
31-25
Reserved
0
Reserved
24-16
USB
0-1FFh
Write a 1 to set equivalent USB interrupt source
Allows the USB interrupt sources to be manually triggered
15-13
Reserved
0
Reserved
12-8
RX
0-1Fh
Write a 1 to set equivalent Receive endpoint interrupt source
Allows the USB interrupt sources to be manually triggered
7-5
Reserved
0
Reserved
4-0
TX
0-Fh
Write a 1 to set equivalent Transmit endpoint interrupt source
Allows the USB interrupt sources to be manually triggered
