Registers
www.ti.com
Figure 53. Receive CPPI DMA State Word 1 (RCPPIDMASTATEW1)
31
16
RXQ_HEAD_PTR
R/W-0
15
2
1
0
RXQ_HEAD_PTR
Reserved
R/W-0
R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 54. Receive CPPI DMA State Word 1 (RCPPIDMASTATEW1) Field Descriptions
Bit
Field
Value
Description
31-2
RXQ_HEAD_PTR
0-1FFF FFFFh
Receive Queue Head Pointer
30-bit pointer to 32-bit aligned descriptor at the head of the Receive queue
1-0
Reserved
0
Reserved
Universal Serial Bus (USB) Controller
106
SPRUGH3 – November 2008
