Printing 3
User Manual 3-35
Manual feed examples: paper, envelopes
Note If you have not selected manual feed in the driver, A-size
(8.5 x 11 in.) or A4-size (212.5 x 275 mm) paper must be fed into
the printer in the same orientation as when it is picked from the
paper tray.
1. A-size (8.5 x 11 in.) and A4-size (210 x 297 mm).
2. Legal-size (8.5 x 14 in.), Tabloid size (11 x 17), A3-size
(297 x 420 mm), and other large paper.
3. Small paper, such as 100 x 150 mm (4 x 6 in.). Be sure to insert the
narrow end of the paper first.
4. Envelopes with the flap open and to the right.
8344-18
Address this side 1234 Main Street Anytown, XX 56789
Return 4321 Main Street Anytown, XX 56789
1 2
3 4
