Moving Your Printer
C-2
Phaser 300X Color Printer
Reinstalling the shipping block
Warning
The printhead remains hot for a while after you turn the
printer off. To avoid injury, wait at least 20 minutes after
turning the printer off before you do the following procedure.
Refer to the drawing on the opposite page while following these steps.
1.
Pull the wire (
A
) to move the printhead (
B
).
2.
Push the tail piece (
A
) down and clip the bottom of the shipping
block (
B
) to the rail.
3.
Slide the shipping block toward the printhead (
A
). Firmly attach
the shipping block to the printhead. Place the shipping block
tightly (
B
) against the printhead.
1B
1A
3A
2A
2B
3B
30987-1
