TDM-E400 / TDM-C400 Ethernet Modem Router User’s Manual
52
Configuring the LAN (Ethernet) Interface
In order to use the device as a router on your LAN, Internet Protocol
(IP) properties must be assigned to the LAN interface. These
properties must identify the interface as residing in the same subnet
as the PCs on your LAN. (See Appendix A for an explanation of
subnets.)
Default IP properties are assigned to the LAN interface to enable
you to connect to it when you configure your PCs as described in
the Quick Start.
Note
If the IP addresses that you want to assign to your PCs are not in
the same subnet as the default LAN interface, you can use Web
Configuration to change the LAN interface IP properties
accordingly. However, because you must access Web
Configuration from a PC in the same subnet as the LAN interface,
initially configure one PC as indicated in the Quick Start. Then,
access Web Configuration and change the LAN IP address as
required. When done, change the IP properties on the PC so that
it is also in the appropriate subnet.
If your network uses a DHCP server (other than the ADSL/Ethernet
Modem Router) to assign IP addresses, you can also configure the
device to accept and use a LAN IP address assigned by that server.
Similarly, if your ISP performs DHCP serving for your network, you
can configure the device to accept an IP address assigned from the
ISP’s server. In this mode, the ADSL Ethernet Modem Router is
considered a DHCP client of your (or your ISP’s) DHCP server.
Note
Ethernet Modem Router itself can function as a DHCP server for
your LAN computers, as described in Chapter 8, but not for its
own LAN interface.
Follow these steps to change the default LAN IP properties or to
configure the LAN interface as a DHCP client:
1. Log into Web Configuration and click the LAN tab.
The LAN Configuration page displays:
