TDM-E400 / TDM-C400 ADSL2+ Ethernet Modem Router User’s Manual
178
4. Select the file, and then click .
The following message box displays at the bottom of the page:
Loading New Software
Please do not interrupt the upgrade process. A status page will appear
automatically when loading is completed (about 1 minute).
When loading is complete, the following message displays (the
file name may differ):
File: TEImage.bin successfully saved to flash. Please reboot for the new image
to take effect.
5. Turn off power to the unit, wait a few seconds, and turn it on
again.
The new software will now be in effect. If the system fails to boot or
is not working properly, contact your ISP for assistance.
Uploading an Image Stored Remotely
Follow this procedure if the upgrade file is available by downloading
from your ISP. Contact your ISP to obtain the server and logon
information required.
1. Log into Web Configuration, click the Admin tab, and then
click Remote Image Upgrade in the task bar.
The Remote Image Upgrade page displays.
Figure 83. Remote Image Upgrade Page
Note
If the page does not display a table as shown in Figure 83, but
displays only the Upload button, skip to step 5. In this case, the
download server IP address, filename, and logon information has
already been hard-coded into your system.
2. In the IP Address text boxes, type the IP address of the
server from which the file is to be downloaded.
3. In the Upgrade File text box, type the complete name of the
file to be downloaded and installed.
The file name can be either TEImage*.bin or TEPatch*.bin,
where * represents any number of characters.
4. In the Username and Password fields, type the logon
information to the ISP's server (if the ISP requires it).
