19
2
Quick Start
This Quick Start provides basic instructions for connecting the
Ethernet Modem Router to a computer or LAN and to the Internet.
f Quick Start Part 1 describes setting up the hardware.
f Quick Start Part 2 describes how to configure Internet
properties on your computer(s) and how to install the
software for using a computer attached to the USB port
(optional).
f Quick Start Part 3 shows you how to configure basic
settings on the Ethernet Modem Router to get your LAN or
PC connected to the Internet.
After setting up and configuring the device, you can follow the
instructions on page 37 to verify that it is working properly.
This Quick Start assumes that you have already established ADSL
service with your Internet service provider (ISP). These instructions
provide a basic configuration that should be compatible with your
home or small office network setup. If necessary, refer to the
subsequent chapters for additional configuration instructions.
Quick Start Part 1 — Connecting the Hardware
In Quick Start Part 1, you connect the device to the phone jack, the
power outlet, and your computer or network.
WARNING
Before you begin, turn the power off for all devices. These
include your computer(s), your LAN hub/switch (if applicable),
and the Ethernet Modem Router .
Figure 1 illustrates the hardware connections. The layout of the
ports on your device may vary from the layout shown. Refer to the
steps that follow for specific instructions.
