118
F8: MIDI
● EXCLUSIVE
The EXCLUSIVE TRANSMIT parameter turns
MIDI transmission of MIDI exclusive data (voice
and setup data)
ON or OFF. The EXCLUSIVE
RECEIVE parameter turns MIDI reception of MIDI
exclusive data generated by external equipment
ON
or OFF. A check mark appears in the MESSAGE
SW EXCLUSIVE TRANSMIT or RECEIVE box
when the corresponding parameter is
ON.
TRANSMIT
This display page allows you to specify which PSR-4000 voices and parts will be transmitted via which MIDI
channels (there are 16 MIDI channels), and to specify which types of data will be transmitted for each channel.
● TRANSMIT MONITOR
The TRANS. MONITOR (transmit monitor) at
the top of the display indicates when data is being
transmitted on any of the 16 MIDI channels: The
dots corresponding to each channel (1 … 16) flash
briefly whenever any data is transmitted on the
channel(s).
● CHANNEL
Use either the ▲ and ▼ LCD buttons to the left
of the display, or the CH LCD [▲/▼] control to
select the channel to which you want to assign a part
or change a data switch setting. The channel num-
bers are show in the leftmost column in the display.
● PART
The PART LCD [▲/▼] controls select the voice
or part which will be transmitted via the currently
selected channel. Only one voice or part can be
specified per channel. Any of the parts listed below
can be selected. If one part is assigned to multiple
channels, only the lowest-numbered channel will be
used.
