62
Effects List
The functions of Reverb parameters are explained.
Explanations for each Reverb Type are given on the
following pages.
01: Stereo Plate
Stereo reverb which simulates plate reverberation (a reverb
unit that uses the vibration of a metallic plate).
02: Stereo OperaHouse
Stereo reverb which simulates the reverberation within a
opera house.
03: Stereo StudioSpring
Stereo reverb which simulates spring reverberation (a reverb
unit that uses the vibration of springs).
Reverb Parameters
Page
01: Stereo Plate p. 62
02: Stereo OperaHouse p. 62
03: Stereo StudioSpring p. 62
04: Stereo Echoes p. 63
05: Stereo Room p. 63
06: Stereo Cathedral p. 63
07: Stereo Church p. 63
08: Room 1 p. 64
09: Room 2 p. 64
10: Room 3 p. 65
11: Hall 1 p. 65
12: Hall 2 p. 66
13: Hall 3 p. 66
14: Garage p. 67
Parameter Value Description
Pre Low Freq 50–4000 Hz Frequency of the low range
Pre Low Gain -15– +15 dB Gain of the low range
Pre Mid Freq 50–20000 Hz Frequency of the middle range
Pre Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0 Width of the middle range
Set a higher value for Q to nar-
row the range to be affected.
Pre Mid Gain -15– +15 dB Gain of the middle range
Pre Hi Freq 2000–20000 Hz Frequency of the high range
Pre Hi Gain -15– +15 dB Gain of the high range
Pre Delay 0–160.0 ms Adjusts the delay time from the
direct sound until the reverb
sound is heard.
Rev Time 1.00–10.00 sec Duration (time) of the reverb
LfDamp Gain -36–0 dB Degree of Low Damp
The Low Damp function damps
the low frequency band of the re-
verb sound quicker than other
bands.
HfDamp Gain -36–0 dB Degree of High Damp
High Damp, by attenuating the
higher frequencies first.
Parameter Value Description
Pre Low Freq 50–4000 Hz Frequency of the low range
Pre Low Gain -15– +15 dB Gain of the low range
Pre Mid Freq 50–20000 Hz Frequency of the middle range
Pre Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0 Width of the middle range
Set a higher value for Q to nar-
row the range to be affected.
Pre Mid Gain -15– +15 dB Gain of the middle range
Pre Hi Freq 2000–20000 Hz Frequency of the high range
Pre Hi Gain -15– +15 dB Gain of the high range
Pre Delay 0–160.0 ms Adjusts the delay time from the
direct sound until the reverb
sound is heard.
Room Size 0–5 Size of the room which is simu-
lated
Rev Time 1.00–10.00 sec Duration (time) of the reverb
LfDamp Gain -36–0 dB Degree of Low Damp
The Low Damp function damps
the low frequency band of the re-
verb sound quicker than other
bands.
HfDamp Gain -36–0 dB Degree of High Damp
High Damp, by attenuating the
higher frequencies first.
Parameter Value Description
Pre Low Freq 50–4000 Hz Frequency of the low range
Pre Low Gain -15– +15 dB Gain of the low range
Pre Mid Freq 50–20000 Hz Frequency of the middle range
Pre Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0 Width of the middle range
Set a higher value for Q to nar-
row the range to be affected.
Pre Mid Gain -15– +15 dB Gain of the middle range
Pre Hi Freq 2000–20000 Hz Frequency of the high range
Pre Hi Gain -15– +15 dB Gain of the high range
Pre Delay 0–160.0 ms Adjusts the delay time from the
direct sound until the reverb
sound is heard.
Rev Time 1.00–10.00 sec Duration (time) of the reverb
LfDamp Gain -36–0 dB Degree of Low Damp
The Low Damp function damps
the low frequency band of the re-
verb sound quicker than other
bands.
HfDamp Gain -36–0 dB Degree of High Damp
High Damp, by attenuating the
higher frequencies first.
