59
Effects List
37: Keyboard Multi
A ring modulator, 3-band equalizer, pitch shifter, phaser, and
delay are connected in series.
Ring Modulator is an effect which applies ring modulation
using an internal oscillator to the input signal, producing bell-
like sounds.
38: Phonograph
This effect reproduces the sound of an analog record played
on a record player. This includes the various noises with the
characteristic of records and the uneven rotation of older
turntables.
Mod Level 0–127 Volume of the chorus or flanger
sound.
Trem/Pan
Sw OFF, ON Turns the tremolo/auto pan effect
on/off.
Trem Mode TREMOLO,
AUTO PAN Selects whether to use tremolo or auto
pan.
Trem
Waveform TRI,
SAWUP,
SAWDN,
SQR, SIN Selects the type of modulation.
TRI: Triangle wave
SAWUP/SAWDN: Sawtooth Wave
SQR: Square wave
SIN: Sine wave
Trem Rate 0.05–10.0
Hz, note Frequency of modulation
Trem Depth 0–127 Depth of modulation
Parameter Value Description
Ring Freq 0–127 Frequency at which modulation
will be applied
Ring Balance DRY100:0WET–
DRY0:100WET Volume balance between the di-
rect sound (DRY) and the ring
modulated sound (WET)
EQ Low Freq 50–4000 Hz Frequency of the low range
EQ Low Gain -15– +15 dB Gain of the low range
EQ Mid Freq 50–20000 Hz Frequency of the middle range
EQ Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0 Gain of the middle range
Set a higher value for Q to nar-
row the range to be affected.
EQ Mid Gain -15– +15 dB Gain of the middle range
EQ Hi Freq 2000–20000 Hz Frequency of the high range
EQ Hi Gain -15– +15 dB Gain of the high range
PS Grade 1–5 Sets the grade of the effect sound.
The higher the value is set, the
more natural-sounding can be
obtained; however, this increases
the delay from the source sound
as well.
PS Coarse -12– +12
semitone Specifies the pitch shift amount
in semitone steps.
PS Fine -100– +100 cent Adjusts the pitch shift amount in
2-cent steps (1 cent = 1/100 of a
semitone).
PS Balance DRY100:0WET–
DRY0:100WET Volume balance between the di-
rect sound (DRY) and the effect
sound (WET)
Phaser Man-
ual 0–127 Specifies the center frequency at
which the sound is modulated.
Parameter Value Description
SAWUP SAWDN
Phaser Rate 0.05–10.0 Hz,
note Specifies the frequency of modu-
lation.
Phaser Depth 0–127 Specifies the depth of modula-
tion.
Phaser Reso-
nance 0–127 Specifies the amount of feedback
for the phaser.
Higher settings will give the
sound a stronger character.
Phaser Mix
Level 0–127 Specifies the volume of the
phase-shifted sound, relative to
the direct sound.
Delay Time 0–650 ms, note Adjusts the delay time from the
direct sound until the delay
sound is heard.
Delay Feed-
back -98– +98 % Adjusts the proportion of the de-
lay sound that is fed back into the
effect. Negative (-) settings will
invert the phase.
Low Damp
Freq 50–4000 Hz Adjusts the frequency below
which sound fed back to the ef-
fect will be cut.
The Low Damp function damps
the low frequency band of the
delay sound quicker than other
bands, which makes for a clearer
delay effect.
Low Damp
Gain -36–0 dB Degree of Low Damp
Hi Damp
Freq 2000–20000 Hz Adjusts the frequency above
which sound fed back to the ef-
fect will be cut.
High Damp, by attenuating the
higher frequencies first, makes
the delay sound more natural.
Hi Damp
Gain -36–0 dB Degree of High Damp
Delay Level 0–127 Volume of the delay sound.
Parameter Value Description
Input Mode MONO, STE-
REO Use this setting to select either a
stereo or monaural record player
for the effect.
Signal Dist 0–127 Degree of distortion
Frequency
Range 0–127 Sets the frequency response of the
record player.
Lowering the value degrades the
frequency characteristics, making
the sound resemble that from an
older system.
Disk Type LP, EP, SP Sets the turntable rotation speed.
LP: 33 1/3 r.p.m.
EP: 45 r.p.m.
SP: 78 r.p.m.
Parameter Value Description
