Roland VC-2 - Manual (Page 46)

46
Effects List
Recommended combination of pre-amp and speaker
07: Auto Wah
Wah is an effect that modifies the frequency characteristics of
a filter over time, producing a unique tone. The wah effect can
change in relation to the volume of the input signal, and/or
cyclically.
08: Humanizer
This adds a vowel character to the sound, making it similar to
a human voice.
MIDDLE open back enclosure 12 x 1 dynamic
JC-120 open back enclosure 12 x 2 dynamic
BUILT IN 1 open back enclosure 12 x 2 dynamic
BUILT IN 2 open back enclosure 12 x 2 condenser
BUILT IN 3 open back enclosure 12 x 2 condenser
BUILT IN 4 open back enclosure 12 x 2 condenser
BUILT IN 5 open back enclosure 12 x 2 condenser
BG STACK 1 sealed enclosure 12 x 2 condenser
BG STACK 2 large sealed enclosure 12 x 2 condenser
MS STACK 1 large sealed enclosure 12 x 4 condenser
MS STACK 2 large sealed enclosure 12 x 4 condenser
METAL
STACK large double stack 12 x 4 condenser
Amp type Speaker type
BG LEAD BG STACK 1–2, MIDDLE
MS1959 II BG STACK 1–2, METAL STACK
MS1959 I+II BG STACK 1–2, METAL STACK
SLDN LEAD BG STACK 1–2, METAL STACK
METAL 5150 BG STACK 1–2, METAL STACK
METAL LEAD BG STACK 1–2, METAL STACK
OD-2 TURBO BUILT IN 1–4
DISTORTION BUILT IN 1–4
FUZZ BUILT IN 1–4
Parameter Value Description
Filter Type LPF, BPF Type of filter
LPF: The wah effect will be applied
over a wide frequency range.
BPF: The wah effect will be applied
over a narrow frequency range
Polarity DOWN, UP When using the volume of the in-
put signal to control the wah effect,
this setting determines whether the
frequency of the filter will be
moved upward (UP) or downward
(DOWN).
Frequency 0–127 Adjusts the frequency at which the
wah effect will apply.
Peak 0–127 Adjusts the amount of the wah ef-
fect that will occur in the range of
the center frequency.
Set a higher value for Q to narrow
the range to be affected.
Trigger Sens 0–127 Adjusts the sensitivity with which
the wah effect is controlled.
Type Cabinet Speaker Microphone
Rate 0.05–10.0 Hz,
note Frequency of modulation
Depth 0–127 Depth of modulation
Ps Low Freq 50–4000 Hz Frequency of the low range
Ps Low Gain -15– +15 dB Gain of the low range
Ps Hi Freq 2000–20000 Hz Frequency of the high range
Ps Hi Gain -15– +15 dB Gain of the high range
Parameter Value Description
Overdrive
Sw OFF, ON Turns Drive on/off.
Drive 0–127 Degree of distortion
Vowel 1 a, e, i, o, u First vowel
Vowel 2 a, e, i, o, u Second vowel
Rate 0.05–10.0 Hz,
note Frequency at which the two vowels
will be switched
Depth 0–127 Effect depth
With a setting of 0, it will be fixed at
Vowel 1.
Trigger Sens -60–0 dB, LFO Level at which the two vowels will
be switched
-60–0 dB: When the specified level
is exceeded, the sound will change
to the other vowel at the frequency
(speed) specified by Rate.
LFO: The two vowel sounds will al-
ternate at the frequency specified
by Rate, regardless of the level.
Ps Low Freq 50–4000 Hz Frequency of the low range
Ps Low Gain -15– +15 dB Gain of the low range
Ps Hi Freq 2000–20000 Hz Frequency of the high range
Ps Hi Gain -15– +15 dB Gain of the high range
Parameter Value Description
