50
Effects List
Delay Pan Type
16: Analog Delay → Chorus
This effect reproduces the sound of the BOSS CE-1 Chorus
Ensemble. To reproduce the sound of the unit at the time, a
monaural analog-type delay is first inserted in series.
17: Digital Chorus
This is a stereo chorus or flanger. Equalizers are provided
before (Pre) and after (Post) the chorus (or flanger).
Balance DRY100:0WET–
DRY0:100WET Volume balance between the di-
rect sound (DRY) and the delay
sound (WET)
Values Dly 1 Dly 2 Dly 3 Dly 4 Dly 5
1 L63 L32 0 32R 63R
2 L63 32R L32 63R 0
3 L63 63R L32 32R 0
4 32R L32 L63 0 63R
5 63R 0 L63 L32 32R
6 L32 32R L63 63R 0
7 0 63R L63 32R L32
8 0 63R L32 32R L63
9 0 32R L32 63R L63
10 63R 32R 0 L32 L63
Parameter Value Description
Dly Sw OFF, ON Turns the delay on/off.
Dly Repeat
Rate 0–127 Corresponds to the delay time in a de-
lay effects.
Dly Intensity 0–127 Corresponds to the feedback setting in
a delay effects.
Dly Level 0–127 Sets the volume of the delay sound.
Chorus Sw OFF, ON Turns chorus or vibrato on/off.
Chorus Mode CHORUS,
VIBRATO Switches the sound between chorus
and vibrato modes.
Chorus Inten-
sity 0–127 When Chorus Mode is CHORUS, this
sets the pitch vibrato speed.
Vibrato
Depth 0–127 When Chorus Mode is VIBRATO, this
sets the pitch vibrato depth.
Vibrato Rate 0–127 When Chorus Mode is VIBRATO, this
sets the pitch vibrato speed.
Chorus Out
Mode MONO,
ST-1, ST-2 Switches the output format (mono/
stereo).
MONO: Output is monaural.
ST-1: Chorus sound of the pitch vibra-
tion which phase is inverted between
left and right is mixed with the source
sound. This is a broader chorus, with
a weaker feeling of placement.
ST-2: The left output contains the
source sound, and the right side has
the wavering chorus sound.
Parameter Value Description
Parameter Value Description
Mode CHORUS,
FLANGER Selects either chorus or flanger.
Rate 0.05–10.0 Hz,
note Sets the cycle for the chorus or
flanger sound undulations.
Depth 0–127 Adjusts the depth of modulation
for the chorus or flanger.
Phase 0–180 deg Specifies the spaciousness of the
chorus or flanger sound.
Pre Low Freq 50–4000 Hz Frequency of the low range (Pre)
Pre Low Gain -15– +15 dB Gain of the low range (Pre)
Pre Hi Freq 2000–20000 Hz Frequency of the high range (Pre)
Pre Hi Gain -15– +15 dB Gain of the high range (Pre)
Pre Dly Time 0–50.0 ms Adjusts the delay time from the di-
rect sound until the chorus or
flanger sound is heard.
Feedback -98– +98 % Adjusts the proportion of the cho-
rus or flanger sound that is fed
back into the effect. Negative (-)
settings will invert the phase.
Xover Low-
Freq 50–4000 Hz Attenuates the effect in the range
below the specified frequency.
Xover Low
Gain -36–0 dB Specifies how greatly the low
range will be attenuated.
Xover HiFreq 2000–20000 Hz Attenuates the effect in the range
above the specified frequency.
Xover Hi
Gain -36–0 dB Specifies how greatly the high
range will be attenuated.
Modulation
Level 0–127 Volume of the chorus or flanger
sound.
Ps Low Freq 50–4000 Hz Frequency of the low range (Post)
Ps Low Gain -15– +15 dB Gain of the low range (Post)
Ps Hi Freq 2000–20000 Hz Frequency of the high range (Post)
Ps Hi Gain -15– +15 dB Gain of the high range (Post)
