Effects List

13: Reverse Delay

Adds the reverse of the input sound as the delay sound.

14: Vocal Echo

This effect simulates a karaoke echo.

15: Band Pass Delay

This is a delay with a band pass filter (a filter that outputs only
a specified frequency range) on each of five delays. A phaser is
included before the delay. Phaser is an effect that adds a
phase-shifted sound to the original sound to create time-
varying change, modulating the sound.

Parameter

Value

Description

Threshold

0–127

Specifies the input level at which
the delay will begin to apply.

Rvs Dly
Time

0–650 ms, note

Specifies the delay time from the
original sound until the delay
sound is heard.

Rvs Feed-
back

-98– +98 %

Adjusts the proportion of the re-
verse delay sound that is fed back
into the effect. Negative (-) set-
tings will invert the phase.

Low Damp
Freq

50–4000 Hz

Adjusts the frequency below
which sound fed back to the effect
will be cut.
The Low Damp function damps
the low frequency band of the de-
lay sound quicker than other
bands, which makes for a clearer
delay effect.

Low Damp
Gain

-36–0 dB

Degree of Low Damp

Hi Damp
Freq

2000–20000 Hz

Adjusts the frequency above
which sound fed back to the effect
will be cut.
High Damp, by attenuating the
higher frequencies first, makes
the delay sound more natural.

Hi Damp
Gain

-36–0 dB

Degree of High Damp

Balance

DRY100:0WET–
DRY0:100WET

Volume balance between the di-
rect sound (DRY) and the effect
sound (WET)

Ps Low Freq

50–4000 Hz

Frequency of the low range

Ps Low Gain

-15– +15 dB

Gain of the low range

Ps Hi Freq

2000–20000 Hz

Frequency of the high range

Ps Hi Gain

-15– +15 dB

Gain of the high range

Parameter

Value

Description

Delay Time

0–650 ms, note

Adjusts the delay time from the di-
rect sound until the delay sound is
heard.

Pre LPF
Freq

500–15000 Hz,
THRU

Sets the filter’s cutoff frequency
(THRU: no filter is used)

Mod Rate

0.05–10.0 Hz,
note

Specifies the modulation speed of
the modulation effect.

Mod Depth

0–127

Specifies the modulation depth of
the modulation effect.

Diffusion

0–100

Specifies the spaciousness of the
delay sound.

Feedback

-98– +98 %

Adjusts the proportion of the delay
sound that is fed back into the ef-
fect. Negative (-) settings will in-
vert the phase.

Hi Damp
Freq

500–15000 Hz,
THRU

Adjusts the frequency above which
sound fed back to the effect will be
cut.
High Damp, by attenuating the
higher frequencies first, makes the
delay sound more natural.

Echo Level

0–127

Volume of the echo sound

Ps Low Freq

50–4000 Hz

Frequency of the low range

Ps Low Gain

-15– +15 dB

Gain of the low range

Ps Hi Freq

2000–20000 Hz

Frequency of the high range

Ps Hi Gain

-15– +15 dB

Gain of the high range

Parameter

Value

Description

Phaser Man-
ual

0–127

Specifies the center frequency at
which the sound is modulated.

Phaser Rate

0.05–10.0 Hz,
note

Specifies the frequency of modu-
lation.

Phaser
Depth

0–127

Specifies the depth of modula-
tion.

Phaser Reso-
nance

0–127

Specifies the amount of feedback
for the phaser.
Higher settings will give the
sound a stronger character.

Phaser Mix
Level

0–127

Specifies the volume of the
phase-shifted sound, relative to
the direct sound.

Delay Time

0–1300 ms, note

Adjusts the delay time from the
direct sound until the each delay
sound is heard.

Fbk Dly
Time

0–1300 ms, note

Adjusts the delay time for the
feedback sound.

Dly Time
Dev

0–1300 ms, note

Specifies the differences in delay
time for each of the delay sounds.

Delay Level

0–127

Adjusts the volume of each delay
sound.

Delay Feed-
back

-98– +98 %

Adjusts the proportion of the de-
lay sound that is fed back into the
effect. Negative (-) settings will
invert the phase.

Delay Pan
Type

1–10

Specifies the pan of each delay
sound.
Ten settings are provided as vari-
ous panning combinations of the
delay sounds (see below).

BPF 1–5 Freq

50–20000 Hz

Sets the center frequency for each
band pass filter (1–5).

BPF 1/2 Q

0.3–24.0

Specify the output bandwidth for
each band pass filter (1–5).

BPF 3/4/5 Q

Parameter

Value

Description
