25
Creating/Editing Patches (Patch mode)
4. When you have finished inputting, touch
to finalize the mic setting name.
There are three pre-effects: compressor, limiter, and noise
suppressor. By using these you can adjust the level of the
sound being sampled.
Noise suppressor: This effect leaves the original sound
untouched, but mutes the noise that is heard during periods of
silence.
Compressor: By reducing high levels and raising low levels,
this effect smoothes out unevenness in volume.
Limiter: By compressing sounds that exceed a specified
volume level, this effect prevents the sound from distorting.
OFF
No pre-effect will be used.
EQ LOW/MID/HIGH (Three-band equalizer)
NS-COMP
Compressor and noise suppressor settings can be made.
For the parameters of the three-band equalizer, refer to
the explanation of
OFF .
NOISE SUPRESSOR
COMPRESSOR
NS-LIMIT
Limiter and noise suppressor settings can be made.
For the parameters of the three-band equalizer, refer to
the explanation of
OFF .
PRE-EFX Type (Pre-Effect Types)
Parameter Value Explanation
EQ
LOW Freq 50, 63, 80, 100, 125, 160,
200, 250, 315, 400, 500,
630, 800, 1000, 1250,
1600, 2000, 2500, 3150,
4000 Hz Selects the frequency
of the low range.
Gain -15– +15 dB Adjusts the gain of
the low frequency.
Positive (+) settings
will emphasize the
low-frequency
range.
EQ
MID Freq 50, 63, 80, 100, 125, 160,
200, 250, 315, 400, 500,
630, 800, 1000, 1250,
1600, 2000, 2500, 3150,
4000, 5000, 6300, 8000,
10000, 12500, 16000,
20000 Hz Selects the frequency
of the middle range.
Q 0.3, 0.4, 0.6, 0.8, 1.0, 1.5,
2.0, 2.5. 3.0, 3.5, 4.0, 5.0,
6.0, 7.0, 8.0, 10.0, 12.0,
14.0, 16.0, 18.0, 20.0 Adjusts the width of
the middle range. Set
a higher value for Q
to narrow the range
to be affected.
Gain -15– +15 dB Adjusts the gain of
the middle range.
Positive (+) settings
will emphasize the
middle range.
EQ
HIGH Freq 2000, 4000, 5000, 6300,
8000, 10000, 12500,
16000, 20000 Hz Selects the frequency
of the high range.
Gain -15– +15 dB Adjusts the gain of
the high frequency.
Positive (+) settings
will emphasize the
high-frequency
range.
MIC LEVEL 0–127 Adjusts the volume
of the mic.
* This is linked with
MIC Level in the
top screen.
Parameter Value Explanation
Thres
(Threshold
Level) -60–0 dB Specifies the level at which the noise
suppressor will begin to operate. When
the signal falls below the specified lev-
el, it will be muted.
Release
(Release
Time) 0–127 Specifies the time from when the noise
suppressor begins to operate until the
volume reaches 0.
Parameter Value Explanation
Gain 0–127 Adjusts the output gain.
Attack (At-
tack Time) 0–127 Specifies the attack time of the input
sound.
Release
(Release
Time) 0–127 Specifies the time from when the compres-
sor begins to operate until the volume
reaches 0.
Level (Out-
put Level) 0–127 Adjusts the volume of the mic.
* This is linked with MIC Level in the top
screen.
Parameter Value Explanation
