48
Effects List
12: Multi Tap Delay
The effect has five delays. Each of the Delay Time parameters
can be specified as a note length of the selected tempo. You
can also set the panning and level of each delay sound.
Delay
Time 0–1300 ms
(MONO),
0–650 ms (STE-
REO, ALTER-
NATE), note Adjusts the delay time from the di-
rect sound until the delay sound is
heard.
L-R Shift 0–650 ms, note Of the left and right delay sounds,
the delay time will be increased for
only one side.
If the L-R order is L
→ R, the R
sound will be later. In the case of
R
→ L, the L sound will be later.
When the mode is set to MONO or
ALTERNATE, this setting will be
ignored.
L-R Order L → R, R → L In STEREO or ALTERNATE mode,
this setting determines which of the
left or right sides has the delay
sound before the other
L
→ R: The left side is expressed first
R → L: The right side is expressed
first
* In MONO mode, this setting will
be ignored.
Feedback -98– +98 % Adjusts the proportion of the delay
sound that is fed back into the ef-
fect. Negative (-) settings will in-
vert the phase.
Low Damp
Freq 50–4000 Hz Adjusts the frequency below which
sound fed back to the effect will be
cut.
The Low Damp function damps the
low frequency band of the delay
sound quicker than other bands,
which makes for a clearer delay ef-
fect.
Low Damp
Gain -36–0 dB Degree of Low Damp
Hi Damp
Freq 2000–20000 Hz Adjusts the frequency above which
sound fed back to the effect will be
cut.
High Damp, by attenuating the
higher frequencies first, makes the
delay sound more natural.
Hi Damp
Gain -36–0 dB Degree of High Damp
Balance DRY100:0WET–
DRY0:100WET Volume balance between the direct
sound (DRY) and the delay sound
(WET)
Ps Low
Freq 50–4000 Hz Frequency of the low range
Ps Low
Gain -15– +15 dB Gain of the low range
Ps Hi Freq 2000–20000 Hz Frequency of the high range
Ps Hi Gain -15– +15 dB Gain of the high range
Parameter Value Description
Parameter Value Description
Delay 1–5 0–1300 ms,
note Specifies the delay time from the
original sound until each delay
sound (Delay 1/2/3/4/5) is heard.
Fbk Dly
Time 0–1300 ms,
note Adjusts the delay time for the feed-
back sound
Feedback -98– +98 % Adjusts the proportion of the delay
sound that is fed back into the ef-
fect. Negative (-) settings will in-
vert the phase.
Delay 1–5
Level 0–127 Adjusts the volume of each delay
sound (Delay 1/2/3/4/5)
Delay 1–5
Pan L63–63R Adjusts the pan of each delay
sound (Delay 1/2/3/4/5)
Low Damp
Freq 50–4000 Hz Adjusts the frequency below which
sound fed back to the effect will be
cut.
The Low Damp function damps the
low frequency band of the delay
sound quicker than other bands,
which makes for a clearer delay ef-
fect.
Low Damp
Gain -36–0 dB Degree of Low Damp
Hi Damp
Freq 2000–20000 Hz Adjusts the frequency above which
sound fed back to the effect will be
cut.
High Damp, by attenuating the
higher frequencies first, makes the
delay sound more natural.
Hi Damp
Gain -36–0 dB Degree of High Damp
Ps Low Freq 50–4000 Hz Frequency of the low range
Ps Low Gain -15– +15 dB Gain of the low range
Ps Hi Freq 2000–20000 Hz Frequency of the high range
Ps Hi Gain -15– +15 dB Gain of the high range
