56
Effects List
31: Enh → Cho/Flg
(Enhancer → Chorus/Flanger)
This effect connects Enhancer and either Chorus or Flanger in
series.
32: Enh → Delay (Enhancer → Delay)
This effect connects an Enhancer and a Delay in series.
33: Vocal Multi
A limiter/de-esser, enhancer, 3-band equalizer, and delay are
connected in series.
A limiter holds down high signal levels to prevent distortion.
A de-esser cuts the sibilant sounds of a voice, producing a
gentler tone.
Parameter Value Description
Enhan Sens 0–127 Sensitivity of the enhancer
Enhan Fre-
quency 0–127 Sets the lower limit of the frequen-
cies to which the enhancement ef-
fect is added.
Enhan Mix
Level 0–127 Level of the overtones generated by
the enhancer
Enhan Level 0–127 Volume of the enhancer sound
Mod Mode CHORUS,
FLANGER Selects whether to use chorus or
flanger.
Mod Rate 0.05–10.0 Hz,
note Adjusts the speed of modulation
for the chorus or flanger.
Mod Depth 0–127 Adjusts the depth of modulation
for the chorus or flanger.
Mod Phase 0–180 deg Sets how the chorus or flanger
sound is spread.
Mod Pre De-
lay 0–50.0 ms Adjusts the delay time from the di-
rect sound until the chorus or
flanger sound is heard.
Mod Feed-
back -98– +98 % Adjusts the proportion of the effect
sound that is fed back into the ef-
fect. Negative (-) settings will in-
vert the phase.
Xover Low-
Freq 50–4000 Hz Attenuates the effect in the range
below the specified frequency.
Xover Low
Gain -36–0 dB Specifies how greatly the low range
will be attenuated.
Xover Hi-
Freq 2000–20000 Hz Attenuates the effect in the range
above the specified frequency.
Xover Hi
Gain -36–0 dB Specifies how greatly the high
range will be attenuated.
Mod Level 0–127 Volume of the chorus or flanger
sound.
Ps Low Freq 50–4000 Hz Frequency of the low range
Ps Low Gain -15– +15 dB Gain of the low range
Ps Hi Freq 2000–20000 Hz Frequency of the high range
Ps Hi Gain -15– +15 dB Gain of the high range
Parameter Value Description
Enhan Sens 0–127 Sensitivity of the enhancer
Enhan Fre-
quency 0–127 Sets the lower limit of the frequen-
cies to which the enhancement ef-
fect is added.
Enhan Mix
Level 0–127 Level of the overtones generated by
the enhancer
Enhan Level 0–127 Volume of the enhancer sound
Delay Time 0–1300 ms,
note Adjusts the delay time from the di-
rect sound until the delay sound is
heard.
Delay Feed-
back -98– +98% Adjusts the proportion of the delay
sound that is fed back into the ef-
fect. Negative (-) settings will in-
vert the phase.
Low Damp
Freq 50–4000 Hz Adjusts the frequency below which
sound fed back to the effect will be
cut.
The Low Damp function damps the
low frequency band of the delay
sound quicker than other bands,
which makes for a clearer delay ef-
fect.
Low Damp
Gain -36–0 dB Degree of Low Damp
Hi Damp
Freq 2000–20000 Hz Adjusts the frequency above which
sound fed back to the effect will be
cut.
High Damp, by attenuating the
higher frequencies first, makes the
delay sound more natural.
Hi Damp
Gain -36–0 dB Degree of High Damp
Delay Level 0–127 Volume of the delay sound.
Ps Low Freq 50–4000 Hz Frequency of the low range
Ps Low Gain -15– +15 dB Gain of the low range
Ps Hi Freq 2000–20000 Hz Frequency of the high range
Ps Hi Gain -15– +15 dB Gain of the high range
Parameter Value Description
Limtr Mode LIMITER,
DE-ESSER Selects whether the effect will
function as a limiter or as a de-ess-
er.
* If the Limtr Mode is DE-ESSER,
the limiter settings are ignored.
Conversely, if the Limtr Mode is
LIMITER, the de-esser settings are
ignored.
Limtr
Threshold -60–0 dB Adjusts the level (Threshold Lev-
el) at which the limiter will begin
to operate.
Limtr Re-
lease 0–127 Adjusts the time until when the
limiter will turn off after the input
level falls below the threshold lev-
el.
Limtr Gain -60– +12 dB Adjusts the gain of the sound that
passes through the limiter.
DE Sens 0–127 Adjusts the sensitivity relative to
the input volume, which controls
how the effect is applied.
DE Frequen-
cy 1000–10000 Hz Adjusts the frequency at which the
de-esser effect will apply.
Parameter Value Description
