Chapter 5
Expert Configuration
E-DOC-CTC-20041126-0013 v1.0
144
Routing Rules The Routing Rules section provides an overview of the existing routing rules.
Proceed as follows to create a new rule:
1 Click New to create a new rule.
2 Fill in all the fields.
Index:
The index of the label rule.
Name:
The name of the rule.
Label:
The label allows to identify packets with matching criteria. If such a
packet arrives it is “labelled” with a packet classification label. Still no
packet classified routing is done. Only if you add a route that uses that
particular label as route criterion, the effective classification based routing
is applied.
Service:
The service or protocol. (e.g. smtp, http, telnet,...)
Source Interface:
The source interface. (e.g. _lan1, _wan1, _dmz1,...)
Source IP select:
The name of the source IP expression.
Destination IP select:
The name of the destination IP expression.
3 Click Apply.
IP QoS Rules The IP QoS Rules section provides an overview of the existing routing rules.
Proceed as follows to create a new rule:
1 Click New to create a new rule.
2 Fill in all the fields.
3 Click Apply.
