Preparation for Installation 4-47
II
L
00
(3) Close the Lower paper guide and Front Cover.
Open and close the Lower paper guide. When Lower Paper Guide and SB Cover Paper
Guide collide, repair it by hand because SB Cover Paper Guide may transform it.
CHECK
Lower Paper Guide
SB Cover Paper Guide
Upper Paper Guide
Lower Paper Guide
SB Cover Paper Guide
