Chapter 1. Installation Requirements
1.1 Application
This specification is applied to the DDP70 Printer for Unpacking, Installing and Adjustment.
1.2 Installation Area
Installation area is shown in Appendix 1.1–1.12 corresponding to Table 1.1.
Table 1.1 Installation area
Appendix Printer Finisher
Transit Pass
Unit Type
DDP
Finisher
SR5000
High Capacity
Hopper
Container
Stacker 1
Container
Stacker 2
1.1 X X
1.2 X X X
1.3 X X
1.4 X X X
1.5 X X X
1.6 X X X X
1.7 X X X
1.8 X X X X
1.9 X X X
1.10 X X X X
1.11 X X X X
1.12 X X X X X
X: Composed
Leave over than 400mm at the rear of the Printer for ventilation. Otherwise
print quality may be degraded.
1.3 Installation Unit
Locations of the leveling bolt and Caster is shown in Appendix 2.1–2.4.
WARNING
