Unpacking 2-15
II L 00
6) Remove the tape for leveling bolt, and take out four wood spacers from accessory box, it puts
on the bottom of leveling bolts (under plastic bag), turned the leveling bolt by using the
Adjustable Open End Wrench, and raised the Container Stacker.
7) Remove the four base packing.
8) Turned the all casters in the same direction.
9) Install the ramp to the bottom of an inclination board. (Ramp is two pieces to both sides).
10) Raised the leveling bolt and remove the wood spacer.
11) Carefully lift down the Container Stacker on the floor.
Caster
ramp
Inclination board
Down
Up
Wood spacer
Leveling bolt
