Ricoh 70E User Manual
Page 90
Preparation for Installation 4-42
II
L
00
CAUTION
If the gap between the Finisher and Container Stacker is not equal from the top
through the bottom, adjust it by the height of the front and rear casters on the paper
exit side of the Finisher.
The jack of the printer is adjusted when the SB cover doesn't open and shut
smoothly, the printer is lowered, and the SB cover opens and shuts smoothly.
(2)
Fix the Finisher to the Printer (front side only).
(TP screw M4x6: 3)
A
B
A=B
II
L
01
