Chapter 3. Preparation for Installation
3.1 Preparation for Installation of the Printer
3.1.1 Removing the Protection Tape and Mat from the Engine
1) Remove the Tapes and Mats from the Engine.
2) Open the Front Cover.
3) Remove the Tapes and TH Packing.
Front Cover
Tape
TH Packing
Tape
Mat
Tape
Tape
Tape
Tape
Mat
Mat
Hopper Cover
Tape
