134 Chapter 7 Configuring application settings
214394-A
Table 50 describes the items on the VLAN Configuration: Port
Information page.
4 Type information in the text boxes, or select from a list.
5 Do one of the following:
• Click Submit.
• Click Back to return to the VLAN Configuration page without making
changes.
The new port-based VLAN configuration appears in the VLAN Table on the
VLAN Configuration page (
Figure 62 on page 133 ).
Modifying a port-based VLAN
To modify an existing port-based VLAN:
1 From the main menu, choose Application > VLAN > VLAN Configuration.
The VLAN Configuration page opens ( Figure 62 on page 133 ).
2 In the VLAN Table section, in the port-based VLAN row of your choice, click
the Modify icon.
The VLAN Configuration: Port Configuration page opens (Figure 63) .
Table 50 VLAN Configuration: Port Information page items
Item Range Description
VLAN 1..4094 The number assigned to the VLAN when the VLAN was created.
VLAN Name 1..16 Type a character string to create a unique name to identify the
VLAN, for example, VLAN1.
