Chapter 7 Configuring application settings
214394-A
b
If you want that port to no longer learn MAC addresses, click the checked
box to uncheck it.
c
Click Submit.
5
In the MAC Security Table section, choose Enabled in the Current Learning
Mode column of the Learn By Ports row.
6
Click Submit.
Adding MAC addresses
To add MAC address to the MAC address-based security system:
1
In the main menu, choose Applications > MAC Address Security > Security
Table.
It may take awhile for the required addresses to be learned. Then, the Security
Table page opens (
).
Figure 56 Security Table page
Note:
You cannot include any of the port values you have chosen for the
secure ports field.
