Chapter 7 Configuring application settings 129
Using Web-based Management for the BayStack 380-24F Gigabit Switch
Creating VLAN Traffic Class Policy
To create a Traffic Class Policy:
1 From the main menu choose Application > VLAN > Configuration > Traffic
Class Policy.
The Configuration > Traffic Class Policy page opens (Figure 62) .
2 In the Traffic Class Policy page, choose a Policy type.
3 In the Queue Weight setting table, select values for the queue weight.
4 Click on the Submit button.
Figure 59 Traffic Class Policy page
Table 47 describes the items on the Traffic Class Policy page
Table 47 Traffic Class Policy items
Item Value Description
Policy Type
Setting Policy Type Specifies the policy type.
Queue Weight
Setting Low Q Weight Specifies the lowest queue weight.
Medium Q
Weight Specifies the medium queue weight
