SuperTrak EX Series User Manual

294

Global LED Display

Global LEDs glow in response to Logical Drive status.

When a Global LED glows amber or red, you must diagnose and resolve the
logical drive problem in the SuperBuild BIOS or in WebPAM PRO.
See “Chapter 8: Troubleshooting” on page 257.

LED

Logical Drive Status

Dark

System off

Green

Normal

Amber

Logical Drive Critical

Red

Logical Drive Offline
