SuperTrak EX Series User Manual
258
Global LED Display
Global LEDs glow in response to Logical Drive status.
Direct LED Display
Direct LEDs, glow and blink in response to the SuperTrak’s firmware status.
LED
Logical Drive Status
Dark
System off
Green
Normal
Amber
Logical Drive Critical
Red
Logical Drive Offline
Fault
LED
Activity
LED
Firmware Status
OFF
OFF
No physical drive
ON
ON
Unconfigured physical drive
OFF
ON
Configured physical drive – Status OK
ON
ON
Configured physical drive – Status Not OK
OFF
ON
Global spare drive – Status OK
ON
ON
Physical drive – Status Dead
ON
ON
Stale condition
Blink
ON
Rebuilding
OFF
Blink
Activity
Blink
ON
Locate physical drive
Blink
ON
Locate logical drive
Blink
ON
Locate disk array
