219
Chapter 7: Technology Background
• Introduction to RAID (below)
• Choosing a RAID Level (page 232)
• Choosing Stripe Block Size (page 236)
• Choosing Sector Size (page 236)
• Choosing Cache Policy (page 237)
• Capacity Coercion (page 238)
• Initialization (page 239)
• Hot Spare Drive(s) (page 239)
• Partition and Format the Logical Drive (page 240)
• RAID Level Migration (page 240)
• Media Patrol (page 248)
• Predictive Data Migration (PDM) (page 248)
• Transition (page 249)
• Critical & Offline Logical Drives (page 253)
Introduction to RAID
RAID (Redundant Array of Independent Disks) allows multiple physical drives to
be combined together in a disk array. Then all or a portion of the disk array is
formed into a logical drive. The operating system sees the logical drive as a
single storage device, and treats it as such.
The RAID software and controller manage all of the individual drives. The
benefits of a RAID can include:
• Higher data transfer rates for increased server performance
• Increased overall storage capacity for a single drive designation (such as, C,
D, E, etc.)
• Data redundancy/fault tolerance for ensuring continuous system operation in
the event of a hard drive failure
Different types of logical drives use different organizational models and have
varying benefits. Also see “Choosing a RAID Level” on page 232. The following
outline breaks down the properties for each type of RAID logical drive:
