SuperTrak EX Series User Manual

150

Managing Disk Arrays

Disk Array Management includes the following functions:

Viewing Disk Arrays (page 150)

Locating a Disk Array (page 150)

Creating a Disk Array (page 151)

Deleting a Disk Array (page 157)

Viewing Disk Array Information (page 157)

Making Disk Array Settings (page 158)

Creating a Logical Drive (page 159)

Deleting a Logical Drive (page 160)

Migrating a Disk Array (page 161)

Rebuilding a Disk Array (page 162)

Running PDM on a Disk Array (page 163)

Transitioning a Disk Array (page 164)

Preparing a Disk Array for Transport (page 164)

Viewing Disk Arrays

To view the disk arrays in this enclosure plus any expanded or cascaded
enclosures:

1.

Click the Subsystem

icon in Tree View.

2.

Click the Disk Arrays

icon.

A list of disk arrays appears in Management View.
Click the DA link to view a specific disk array. See “Viewing Disk Array
Information” on page 157.

Locating a Disk Array

Virtual or Third Party Enclosures

Support for this feature depends on how your system or enclosure was set up.
Direct-connect systems with individual LED connections and SGPIO enclosures
support individual physical drive LEDs. Other systems or enclosures might or
might not support them. See “Appendix D: LED Backplane Connections” on
page 291.

To locate a disk array in the enclosure, click the Locate DAx button. The LEDs
for the carriers holding the physical drives used by the disk array will blink for one
minute.
