SuperTrak EX Series User Manual
10
Figure 1. SuperTrak EX4650 card
Figure 2. SuperTrak EX8650 card
BBU module
connector
SuperSwap connector
Activity and
Fault LED Pins
Ch1-4
Global and
Aggregate
LED Pins
SAS Ports
Activity and
Fault LED Pins
Ch1-4
BBU module
connector
SuperSwap connector
Global and
Aggregate
LED Pins
Ch5-8
SAS Ports
