B. Technical Specifications
B-3
3830-A2-GB91-20
November 1996
Table B-1
(3 of 4)
Model 3830 Technical Specifications
Specifications
Description
POWER
CONSUMPTION
5.25 watts (typical, including power
transformer, speaker off)
DIMENSIONS
Weight
Height
Width
Depth
2.5 pounds (1.14 kg) (not including power
transformer)
2.1 inches (5.4 cm)
7.6 inches (19.4 cm)
12.1 inches (30.8 cm)
TRANSMIT LEVEL
Dial Line
Leased Line
Permissive (–9 dBm)
Programmable (transmit level defined by
TELCO)
0 through –15 dBm (in 1 dBm decrements)
TELEPHONE
INTERFACE
Dial-Line Connectivity
Leased-Line Connectivity
RJ11C Permissive
RJ45S Programmable
6-pin center pair leased jack
(For JM8 connection, refer to Appendix C
for JM8 conversion cable pinouts.)
VOICE FREQUENCY
LINE REQUIREMENTS
2-wire dial (PSTN) or 2-wire leased line
