COMSPHERE 3800 Series Modems – Model 3830
4-34
November 1996
3830-A2-GB91-20
Table 4-3
(6 of 15)
Model 3830 S-Registers
S43
V.32 bis Train
Register controls the modem’s train time for V.32 bis/V.32 mode.
Register has the following values:
0 = Long (A long train is required for satellite links which have long
roundtrip delays.)
1 = Short
Factory setting is Long.
S44
Leased-Line Rate
Determines the modem’s highest data rate and modulation scheme for
operation on 2-wire leased lines in either Answer or Originate mode.
Register has the following values:
0 = 14,400 (V.32 bis)
1 = 14,400 (V.32 bis)
2 = 12,000 (V.32 bis)
3 = 9600 (V.32 bis)
4 = 7200 (V.32 bis)
5 = 4800 (V.32 bis)
6 = 2400 (V.22bis)
18 = 19,200 (V.32
terbo)
19 = 16,800 (V.32
terbo)
Factory setting is 19,200 (V.32
terbo).
S45
Leased Line Transmit Level
Level Determines the modem’s transmit power output level over leased
lines.
Enter a value from 0–15 dBm.
Factory setting is 0 dBm.
