Traps & MIBs
C-19 6371-A2-GB20-10 August 2000
DSL Endpoint MIB
This DSL Endpoint MIB, pdn_DslEndpoint.mib, facilitates configuration of DSL
multirate products and is fully supported. Objects are clarified in Table C-12.
The groups in this MIB are:
H IP Routing Group – This table is an extension of the ipCidrRoute table (see
IP CIDR Route Group (RFC 2096) on page C-8.
H
IP Multicast Group
H IP Processing Group
H
Console Group
Table C-12. DSL Endpoint Configuration Group Objects Table
Object Description Setting/Contents
ipCidrRouteUpstreamNextHop
(IpCidrRouteXEntry 1) Corresponds to the upstream Next Hop
Router address. If the DSL interface is
numbered, each upstream Next Hop Router
address must be in a subnet defined by a
DSL interface IP address and subnet mask. H Ethernet Interface IP address.
H 0.0.0.0 – No upstream next hop
is identified.
ipCidrRouteDownstreamValid
(IpCidrRouteXEntry 2) If false, the row containing it is not valid for
downstream routing. H true
H false
ipCidrClearAllRoutes
(IpCidrRouteX 2) If set to clear, all IP routes are removed from
the routing table. H noOp
H clear
ipCidrRouterID
(IpCidrRouteX 3) Specifies the router ID (primary IP address). Must be equal to a nonzero value
for the interface IP address.
pdnlpMulticastEnable
(pdnRouterConfiguration 1) Enables or disables forwarding of IP
multicast packets. H enable
H disable
pdnlpProcessingEnable
(pdnRouterConfiguration 2) Enables or disables service domain
processing of IP packets. This setting is retained across
power cycles.
pdnConsoleEnabled
(pdnRouterConfiguration 7) Enables or disables the console port. H true(1) – Enable.
H false(2) – Disable.
