191
10
Appen
d
ix
Movie (approximate recording time)
Frame Rate
Recorded Pixels
30fps 15fps Sound
640×480 50 sec. 1 min. 50 sec.
2 hr. 12 min.
320×240 1 min. 30 sec. 2 min. 50 sec.
White Balance Auto, Daylight, Shade, Tungsten Light, Fluorescent Light (W/N/D),
Manual
Lens Focal Length 7.8mm - 39 mm (equivalent to 37.5 mm - 187.5
mm in 35 mm format)
Maximum
Aperture
f2.8 - f4.6
Lens
Composition
9 elements in 7 groups
(two aspherical elements)
Zoom Type Electrically driven
Picture Range Approx. 33.7 mm × approx. 24.7 mm (screen is
filled) (Super Macro mode)
Digital Zoom Capture Mode Max. 8× (combines with 5× optical zoom to
give zoom magnification equivalent to 40×)
Viewfinder Type Real-image zoom viewfinder
(diopter adjustable from –3 m
-1
to +1 m
-1
)
Magnification Wide: 0.37×, Tele: 1.66×
LCD Monitor 1.8 inch CG silicon TFT color LCD monitor (microreflective), with
brightness adjustment, approx. 134 kilopixels (with backlight),
with swivel mechanism (270° vertically and 180° horizontally)
Playback Function Single-frame, 9-frame index, enlargement (max. 10×), scroll,
rotating, sound, slideshow, movie playback, histogram display,
digital filter, trimming, resize
Focus Mode Auto Focus, Macro, Super Macro, Manual Focus, Focusing Area
Autofocus Type TTL contrast detection system by sensor
(with external passive sensor)
11 point autofocus (wide/spot changeable)
Distance
measuring mode
Single, continuous
Focusing
Range
(from lens
front)
Normal : Approx. 0.6 m -
∞
(full zoom range)
Macro : Approx. 0.15 m - 0.65 m
(full zoom range)
Super Macro : Approx. 0.02 m - 0.65 m
(Wide only)
Landscape :
∞
(full zoom range)
Focus Lock By half-pressing shutter release button
Auxiliary AF
light
LED automatically lights in dim surrounding
