Chapter 3 Printer Configuration
80
Host Interface Menu
The printer provides the following host interface options:
• Centronics
®
parallel
• Dataproducts
®
parallel (requires optional cable adapter, p/n
703316-001)
• Serial (RS-232 or RS-422)
NOTE: In addition to the software configuration for the serial
interface, a toggle switch on the right side of the printer
(adjacent to the RS232/422 connector) must be set for
either RS-232 or RS-422. The location of the RS-232/422
toggle switch is shown in Chapter 1, “Introduction.”
The configuration options for each interface type are shown in the
illustrations on the following pages. Descriptions of the options
follow each illustration. Set these options to meet the specific data
communication requirements of the host computer as well as the
application running on the host.
NOTE: For interface connector pin assignments and additional
host interface signal information, see Appendix C, “Host I/O
Interfaces.”
