Chapter 2 Using The Control Panel
46
6. Check paper input to the printer to insure the first paper
perforation is facing the printer and reload paper, if necessary,
to align the first paper perforation.
7. If the Reprint on Fault option is enabled in the Paper Control
menu, the printer reprints the applicable pages. (See the Paper
Control menu on page 68. Also see “Reprinting Pages after
Fault Condition” on page 212.)
8. Press the ONLINE key on the printer control panel, to place the
printer online.
Using The Control Panel
Legend:
1) Status Indicators
2) Liquid Crystal Display (LCD)
3) Paper Path Diagram
4) Function Keys
The control panel is located on the top right side of the front cover.
The LCD, status indicators, and function keys are described on the
following pages.
4
2 1 3
JOB IN
PROCESS
STAND BY LINE
SYNC
SYS
AVAIL
ONLINE FAULT
ONLINE CLEAR TEST SHIFT
CANCEL
PAGE
EJECT
ENTER
PREV
UP
NEXT
DOWN
FUSER DRUM
PAPER PATH
