Install the upper and lower pickup roller units, B. tighten the green thumb screw, 1) hole in frame – Printronix L5035 User Manual
Page 185: 2) coupling, 3) shaft pin, 4) alignment pin
Cleaning The Cut Sheet Option Rollers
185
6.
Install the upper and lower pickup roller units:
a.
Align the shaft pin with the slot in the coupling, and align
the alignment pin on the unit with the hole in the frame.
b.
Tighten the green thumb screw.
Legend:
1)
Hole in Frame
2)
Coupling
3)
Shaft Pin
4)
Alignment Pin
1
2
3
4
