Chapter 3
Printer Configuration
64
Saving Configurations
IMPORTANT
If you do not save your configuration, all of the new values will
be lost when you turn off the printer.
You can save up to eight different configuration sets to meet eight
unique print job requirements. For example:
Config. 0: Factory Default (This cannot be altered)
Config. 1: Selects Image Width of 4 inches
Selects Paper Length of 10 inches.
Config. 2: Selects Image Width of 8 inches
Selects Paper Length of 11 inches.
The configurations are saved and stored in flash memory for later
use. These user-defined configuration sets are erased from
memory when the printer power is turned off. If you do not save
your configuration before you turn off the printer, the current
configuration is lost.
Configuration 0 is a factory-preset configuration that cannot be
changed or saved.
Perform the following steps to save a new configuration:
