Chapter 4

Consumable Replacement

146

10. Vacuum the toner from the toner spray-guard brush on the

developing unit.

11. Shake the new developer bottle several times, remove the

bottle cap, and screw the nozzle tightly onto the bottle.

12. While rotating the developing roller knob counterclockwise,

evenly pour the entire bottle of developer powder into the
developing unit.

Legend:

1)

Developer Bottle

2)

Developing Roller Knob

13. Replace the cover and tighten the screws.

IMPORTANT

If toner or developer spills on clothing, use cold water to
remove it.

14. Install the developing unit into the printer (see step 1 through

step 8, starting on page 140).

1

2
