Install the upper and lower reverse roller units, B. tighten the green thumb screw, 1) hole in frame – Printronix L5035 User Manual
Page 188: 2) shaft pin, 3) alignment pin, 4) coupling, Chapter 5
Chapter 5
General Cleaning
188
10. Install the upper and lower reverse roller units:
a.
Align the shaft pin with the slot in the coupling, and align
the alignment pin on the unit with the hole in the frame.
b.
Tighten the green thumb screw.
Legend:
1)
Hole in Frame
2)
Shaft Pin
3)
Alignment Pin
4)
Coupling
11. Install the upper and lower paper cassettes into the printer.
1
3
2
4
