Configuring Bridge MIB Extensions
The Bridge MIB includes extensions for managed devices that support
Traffic Classes and Virtual LANs. To display and configure these
extensions, use the Extended Bridge Configuration screen as shown below.
Extended Bridge Configuration
=============================
Bridge Capability : (Read Only)
Extended Multicast Filtering Services : NO
Traffic Classes
: YES
Static Entry Individual Port : YES
VLAN Learning : SVL
Configurable PVID Tagging : YES
Local VLAN Capable : NO
Bridge Settings :
Traffic Class : TRUE
GMRP
: DISABLED
GVRP : DISABLED
Use or arrow keys to move. to scroll option.
Parameter Description
Bridge Capability
Extended Multicast
Filtering Services
This switch does not support filtering of individual
multicast addresses based on GMRP (GARP Multicast
Registration Protocol).
Traffic Classes This switch provides mapping of user priorities to
multiple traffic classes. (Refer to “802.1p Port Traffic
Class Information” on page 2-55.)
Static Entry Individual
Port
This switch allows static filtering for unicast and
multicast addresses. (Refer to Network Monitor Menu
/ Static Unicast Address Table Configuration and Static
Multicast Address Table Configuration.)
VLAN Learning This switch uses Shared VLAN Learning (SVL),
whereby the VLAN filtering database is shared among
all ports.
