Configuring Bridge MIB Extensions
The Bridge MIB includes extensions for managed devices that support
Traffic Classes and Virtual LANs. To display and configure these
extensions, use the Bridge Extension screen as shown below:
Bridge Capability
Parameter Description
Extended Multicast
Filtering Services*
This switch does not support filtering of individual multicast
addresses based on GMRP (GARP Multicast Registration
Protocol).
Traffic Classes This switch provides mapping of user priorities to multiple
traffic classes. (Refer to the Priority menu on page 3-31.)
Static Entry Individual
Port
This switch enables static filtering for unicast and multicast
addresses. (Refer to the Address Table Configuration on
page 3-20.)
VLAN Learning This switch uses Shared VLAN Learning (SVL), where the
VLAN filtering database is shared among all ports.
Configurable
PVID Tagging
This switch allows you to override the default PVID (Port
VLAN ID) assigned to untagged incoming frames under
VLAN Port Configuration on “VLAN Port Configuration”
on page 3-41.
Local VLAN Capable* A local bridge (that is, dedicated Spanning Tree) is applied
to each individual VLAN.
* These functions are not available for the current firmware release.
