U
SING THE
S
YSTEM
C
ONFIGURATION
P
ROGRAM
2-12
Changing the Network Configuration
Use the Network Configuration menu to set the bootup option, configure
the switch’s Internet Protocol (IP) parameters, enable the on-board Web
agent, or to set the number of concurrent Telnet sessions allowed. The
screen shown below is described in the following table.
TFTP Download Downloads new version of firmware to update
your system (in-band).
Configuration Save
& Restore
Saves the switch configuration to a file on a TFTP
server. This file can be later downloaded to
restore the configuration.
Network Configuration
=====================
IP Configuration ...
IP Connectivity Test (Ping) ...
HTTP Configuration ...
MAX Number of allowed Telnet sessions (1 -4) : 4
MAC Address : 00-E0-29-52-28-00
Use or arrow keys to move. to select.
Parameter Description
IP Configuration Screen used to set the bootup option, or
configure the switch’s IP parameters.
IP Connectivity Test (Ping) Screen used to test IP connectivity to a specified
device.
HTTP Configuration Screen used to enable the Web agent.
MAX Number of Allowed
Telnet Sessions
The maximum number of Telnet sessions allowed
to simultaneously access the agent module.
MAC Address Physical address of the agent module.
Menu Description
