U
SING THE
S
YSTEM
C
ONFIGURATION
P
ROGRAM
2-4
Management Setup Menu
Network Configuration Includes IP setup, Ping facility, HTTP (Web agent)
setup, Telnet configuration, and MAC address.
Serial Port Configuration Sets communication parameters for the serial port,
including management mode, baud rate, console
time-out, and screen data refresh interval.
SNMP Configuration Activates traps; and configures communities and
trap managers.
Console Login
Configuration
Sets user names and passwords for system access, as
well as the invalid password threshold and lockout
time.
TFTP Download Downloads new version of firmware to update your
system (in-band).
Configuration Save
& Restore
Saves the switch configuration to a file on a TFTP
server. This file can be later downloaded to restore
the configuration.
Management Configuration Specifies if management access to the switch is
available from all VLANs or restricted to one
VLAN.
Device Control Menu
Port Configuration Enables any port, enables/disables flow control,
and sets communication mode to auto-negotiation,
full duplex or half duplex.
Port Information Displays operational status, including link state,
flow control method, and duplex mode.
Spanning Tree Configuration Enables Spanning Tree Algorithm; also sets
parameters for hello time, maximum message age,
switch priority, and forward delay; as well as port
priority, path cost, and fast forwarding.
Spanning Tree Information Displays full listing of parameters for the Spanning
Tree Algorithm.
Port Mirror Configuration Sets the source and target ports for mirroring.
Port Trunking Configuration Specifies ports to group into aggregate trunks.
IGMP Configuration
Configures IGMP multicast filtering.
Menu Description
