U
SING THE
S
YSTEM
C
ONFIGURATION
P
ROGRAM
2-32
Viewing the Current Port Configuration
The Port Information screen displays the port type, status, link state, and
flow control in use, as well as the communication speed and duplex mode.
To change any of the port settings, use the Port Configuration menu.
Port Information : Unit 1 Port 1 - 12
================
Port Type Operational Link FlowControl Speed and
InUse Duplex InUse
----------------------------------------------------------------
1. 100FX YES UP NONE 100-FULL
2. 100FX YES UP NONE 100-FULL
3. 100FX YES UP NONE 100-FULL
4. 100FX YES UP NONE 100-FULL
5. 100FX YES UP NONE 100-FULL
6. 100FX YES UP NONE 100-FULL
7. 100FX YES UP NONE 100-FULL
8. 100FX YES UP NONE 100-FULL
9. 100FX YES UP NONE 100-FULL
10. 100FX YES UP NONE 100-FULL
11. 100FX YES UP NONE 100-FULL
12. 100FX YES UP NONE 100-FULL
Use or arrow keys to move. to select.
Parameter Description
Type Shows port type as:
100FX :
100BASE-FX
1000SX : 1000BASE-SX
1000LX : 1000BASE-LX
1000T : 1000BASE-T
Operational Shows if the port is functioning or not.
Link Indicates if the port has a valid connection to an
external device.
