Main Menu
Using the on-board Web agent, you can define system parameters, manage
and control the switch, the connected stack and all its ports, or monitor
network conditions. The following table briefly describes the selections
available from this program.
Menu Description
System Provides basic system description, including contact information.
Switch Shows hardware/firmware version numbers, power status, and
expansion modules in use.
IP Includes boot state, IP address, and the maximum number of Telnet
sessions allowed.
SNMP Configures communities, trap managers; and activates traps.
Security Sets password for system access.
Upgrade Downloads new version of firmware to update your system.
Configure Saves the switch configuration to a file on a TFTP server.
Address
Table
Provides full listing of unicast addresses, sorted by address or
VLAN.
STA Enables Spanning Tree Algorithm; also sets parameters for switch
priority, hello time, maximum message age, and forward delay; as
well as port priority and path cost.
Bridge
Extension
Displays/configures extended bridge capabilities for this switch,
including for traffic classes and VLAN extensions.
Priority Configures default port priorities and displays queue assignments.
VLAN Configures VLAN group members and other port-specific VLAN
settings.
IGMP Configures IGMP multicast filtering.
Port Enables any port, sets communication mode to auto- negotiation,
full duplex or half duplex, enables/disables flow control, configures
broadcast control and port security.
Mirror Sets the source and target ports for mirroring.
Trunk Specifies ports to group into aggregate trunks.
Statistics Displays statistics on network traffic passing through the selected
port.
