P
ORT
S
TATISTICS
3-57
Note: Statistics are automatically refreshed every 60 seconds.
Oversize Frames The total number of frames received that were longer than
1518 octets (excluding framing bits, but including FCS
octets) and were otherwise well formed.
Fragments The total number of frames received that were less than 64
octets in length (excluding framing bits, but including FCS
octets) and had either an FCS or alignment error.
Jabbers The total number of frames received that were longer than
1518 octets (excluding framing bits, but including FCS
octets), and had either an FCS or alignment error.
Collisions The best estimate of the total number of collisions on this
Ethernet segment.
64 Byte Frames The total number of frames (including bad packets)
received and transmitted that were 64 octets in length
(excluding framing bits but including FCS octets).
65-127 Byte Frames The total number of frames (including bad packets)
received and transmitted that were between 65 and 127
octets in length inclusive (excluding framing bits but
including FCS octets).
128-255 Byte Frames The total number of packets (including bad packets)
received and transmitted that were between 128 and 255
octets in length inclusive (excluding framing bits but
including FCS octets).
256-511 Byte Frames The total number of packets (including bad packets)
received and transmitted that were between 256 and 511
octets in length inclusive (excluding framing bits but
including FCS octets).
512-1023 Byte Frames The total number of packets (including bad packets)
received and transmitted that were between 512 and 1023
octets in length inclusive (excluding framing bits but
including FCS octets).
1024-1518 Byte
Frames
The total number of packets (including bad packets)
received and transmitted that were between 1024 and 1518
octets in length inclusive (excluding framing bits but
including FCS octets).
Parameter Description
